Product Details
product information:
Structure:Spherical Roller Bearings
Type:Spherical Roller Bearings
Brand Name:YWS
Internal diameter:55mm
External diameter:100mm
Width:25mm
size:55x100x25mm
Material:Chrome steel/GCr15/Stainless steel/ceramic/ZrO2
Is customized: Yes (Drawings required)
Wholesale and freight: To provide you with accurate solutions
Tips: Please contact us for details of the required products.
Product description:
This spherical roller bearing has a steel cage, a CN radial clearance, and a straight bore suitable for applications that support high radial and oscillating axial loads, such as in a belt conveyor system. The two-piece pressed steel window-type cage has high wear resistance, and it spaces the rollers for even load distribution and prevents contact to reduce friction, vibration, and noise. A flangeless inner ring guides the cage. This roller bearing's CN (normal) radial clearance is for applications where thermal expansion does not reduce clearance. The bearing's straight bore fits conventional cylindrical shafts. This bearing has two rows of symmetrically arranged rollers oriented on a concave raceway, which allow self-realignment and compensate for static and dynamic alignment errors. The bearing has a maximum operating temperature of 392 degrees F. This roller bearing is intended for interchangeability and meets Deutsches Institut für Normung (DIN) standards for parts numbering, bearing dimensions, load ratings, tolerances, and clearances. It meets International Standards Organization (ISO) standards for hardening of bearing rollers and rings. This spherical barrel roller bearing is suitable for use in material handling equipment, electric generators, and machine tools.
Product features:
Two row spherical roller bearing suitable for applications that support high radial and oscillating axial loads
Two-piece pressed steel window-type cage has high wear resistance and spaces the rollers for even load distribution and prevents contact to reduce friction, vibration, and noise
Flangeless inner ring with cage guide
CN (normal) radial clearance for applications where thermal expansion is not a factor
Straight bore fits conventional cylindrical shafts
MODEL | d(mm) | D(mm) | B(mm) |
22211E | 55 | 100 | 25 |
22211EK | 55 | 100 | 25 |
21311E | 55 | 120 | 29 |
21311EK | 55 | 120 | 29 |
22311E | 55 | 120 | 43 |
22311EK | 55 | 120 | 43 |
22212E | 60 | 110 | 28 |
22212EK | 60 | 110 | 28 |
21312E | 60 | 130 | 31 |
21312EK | 60 | 130 | 31 |
22312E | 60 | 130 | 46 |
22312EK | 60 | 130 | 46 |
24013CC/W33 | 65 | 100 | 35 |
24013cck30/w33 | 65 | 100 | 35 |
22213e | 65 | 120 | 31 |
22213ek | 65 | 120 | 31 |
21313E | 65 | 140 | 33 |
21313EK | 65 | 140 | 33 |
22313E | 65 | 140 | 48 |
22313EK | 65 | 140 | 48 |
22214E | 70 | 125 | 31 |
22214EK | 70 | 125 | 31 |
21314E | 70 | 150 | 35 |
21314EK | 70 | 150 | 35 |
22314E | 70 | 150 | 51 |
22314EK | 70 | 150 | 51 |
24015CC/W33 | 75 | 115 | 40 |
24015CCK30/W33 | 75 | 115 | 40 |
22215E | 75 | 130 | 31 |
22215ek | 75 | 130 | 31 |
21315E | 75 | 160 | 38 |
22315E | 75 | 160 | 55 |
22315EK | 75 | 160 | 55 |
Sincerely welcome to send enquiry to us!!!
