Product Details
product information:
Structure:Spherical Roller Bearings
Type:Spherical Roller Bearings
Brand Name:YWS
Internal diameter:110mm
External diameter:170mm
Width:45mm
size:110×170×45mm
weight: 4.22kg
Material:Chrome steel/GCr15/Stainless steel
Is customized: Yes (Drawings required)
Wholesale and freight: To provide you with accurate solutions
Tips: Please contact us for details of the required products.
Product description:
The spherical radial bearing has symmetric races to support radial loads while maintaining high speeds and rotational accuracy. It has a straight bore that fits conventional cylindrical shafts, and it has a CN (normal) radial internal clearance for applications that do not involve thermal expansion. Its steel cage evenly spaces the rollers for even load distribution and prevents contact to reduce friction, vibrations, and noise. This radial ball bearing is suitable for use in general purpose applications that primarily involve radial loads and minimal axial loads at relatively high rotational speeds. These include transmissions, motors, and pumps, among others.
Product features:
Axially symmetric races to support radial loads while maintaining high speeds and rotational accuracy
Straight bore fits conventional cylindrical shafts
CN (normal) radial internal clearance for applications that do not involve thermal expansion or atypical precision
Steel cage evenly spaces the rollers for even load distribution and prevents contact to reduce friction, vibrations, and noise
Three lubrication holes in the outer ring for lubrication in place
MODEL | d(mm) | D(mm) | B(mm) |
23022CC/W33 | 110 | 170 | 45 |
23022CCK/W33 | 110 | 170 | 45 |
24022CC/W33 | 110 | 170 | 60 |
24022CCK/W33 | 110 | 170 | 60 |
23122CC/W33 | 110 | 180 | 56 |
23122CCK/W33 | 110 | 180 | 56 |
24122CC/W33 | 110 | 180 | 69 |
24122CC/K/W33 | 110 | 180 | 69 |
22222E | 110 | 200 | 53 |
22222EK | 110 | 200 | 53 |
23222CC/W33 | 110 | 200 | 69.8 |
23222CCK/W33 | 110 | 200 | 69.8 |
22322e | 110 | 240 | 80 |
22322ek | 110 | 240 | 80 |
23024CC/W33 | 120 | 180 | 46 |
23024CCK/W33 | 120 | 180 | 46 |
24024CC/W33 | 120 | 180 | 60 |
24024CCK/W33 | 120 | 180 | 60 |
23124CC/W33 | 120 | 200 | 62 |
23124CCK/W33 | 120 | 200 | 62 |
24124CC/W33 | 120 | 200 | 80 |
24124CCK/W33 | 120 | 200 | 80 |
22224E | 120 | 215 | 58 |
22224EK | 120 | 215 | 58 |
23224CC/W33 | 120 | 215 | 76 |
232244CCK/W33 | 120 | 215 | 76 |
22324CC/W33 | 120 | 260 | 86 |
22324CCK/W33 | 120 | 260 | 86 |
23026cc/w33 | 130 | 200 | 52 |
23026cck/w33 | 130 | 200 | 52 |
24026cc/w33 | 130 | 200 | 69 |
24026cck/w33 | 130 | 200 | 69 |
23126cc/w33 | 130 | 210 | 64 |
23126cck/w33 | 130 | 210 | 64 |
24126cc/w33 | 130 | 210 | 80 |
24126cck/w33 | 130 | 210 | 80 |
22226e | 130 | 230 | 64 |
22226ek | 130 | 230 | 64 |
23266cc/w33 | 130 | 230 | 80 |
23266cck/w33 | 130 | 230 | 80 |
22326cc/w33 | 130 | 280 | 93 |
22326cck/w33 | 130 | 280 | 93 |
