Product Details
Chinese professional supplier self-aligning roller bearing 21317
product information:
Structure:Spherical Roller Bearing
Type:Spherical Roller Bearing
Brand Name:YWS
Internal diameter:85mm
External diameter:180mm
Width:41mm
size:85×180×41mm
Material:Chrome steel/GCr15/Stainless steel
Is customized: Yes (Drawings required)
Related accessories: Oil seal,Circlip and housings etc.
Wholesale and freight: To provide you with accurate solutions
Tips: Please contact us for details of the required products.
Product description:
The spherical radial bearing has symmetric races to support radial loads while maintaining high speeds and rotational accuracy. It has a straight bore that fits conventional cylindrical shafts, and it has a C3 radial internal clearance for radial slack between the inner and outer rings that is greater than CN (normal) to compensate for thermal expansion. Its steel cage evenly spaces the rollers for even load distribution and prevents contact to reduce friction, vibrations, and noise. This radial ball bearing is suitable for use in general purpose applications that primarily involve radial loads and minimal axial loads at relatively high rotational speeds. These include transmissions, motors, and pumps, among others.
Product features:
Axially symmetric races to support radial loads while maintaining high speeds and rotational accuracy
Straight bore fits conventional cylindrical shafts
C3 radial internal clearance for radial slack between the inner and outer rings is greater than CN (normal) to compensate for thermal expansion
Steel cage evenly spaces the rollers for even load distribution and prevents contact to reduce friction, vibrations, and noise
MODEL | d(mm) | D(mm) | B(mm) |
22205/20E | 20 | 52 | 18 |
22205E | 25 | 52 | 18 |
22205EK | 25 | 52 | 18 |
21305CC | 25 | 62 | 17 |
22206E | 30 | 62 | 20 |
22206EK | 30 | 62 | 20 |
21306CC | 30 | 72 | 19 |
21306CCK | 30 | 72 | 19 |
22207E | 35 | 72 | 23 |
22207EK | 35 | 72 | 23 |
21307CC | 35 | 80 | 21 |
21307CCK | 35 | 80 | 21 |
22208E | 40 | 80 | 23 |
22208EK | 40 | 80 | 23 |
21308E | 40 | 90 | 23 |
21308EK | 40 | 90 | 23 |
22308E | 40 | 90 | 33 |
22308EK | 40 | 90 | 33 |
22209E | 45 | 85 | 23 |
22209EK | 45 | 85 | 23 |
21309E | 45 | 100 | 25 |
21309EK | 45 | 100 | 25 |
22309E | 45 | 100 | 36 |
22309EK | 45 | 100 | 36 |
22210E | 50 | 90 | 23 |
22210EK | 50 | 90 | 23 |
21310E | 50 | 110 | 27 |
21310EK | 50 | 110 | 27 |
22310E | 50 | 110 | 40 |
22310EK | 50 | 110 | 40 |
