Product Details
product information:
Item: 23122 CA
Structure:Spherical
Type: Spherical Roller bearings
Brand Name:YWS
Internal diameter:110mm
External diameter:180mm
width:56mm
size:110×180×56mm
weight:5.73kg
Material:Chrome steel/GCr15/Stainless steel
Sealing type: You can choose Metal seal Or Rubber seal
Is customized: Yes (Drawings required)
Related accessories: Oil seal,Circlip and housings etc.
Wholesale and freight: To provide you with accurate solutions
Product description:
This spherical roller bearing has a steel cage, a C3 radial clearance, and a straight bore suitable for applications that support high radial and oscillating axial loads, such as in a belt conveyor system. The two-piece pressed steel window-type cage has high wear resistance, and it spaces the rollers for even load distribution and prevents contact to reduce friction, vibration, and noise. A flangeless inner ring guides the cage. The bearing’s C3 radial clearance is larger than normal for applications where impact loads and vibration are severe, or thermal expansion is a factor. The bearing's straight bore fits conventional cylindrical shafts. This bearing has two rows of symmetrically arranged rollers oriented on a concave raceway, which allow self-realignment and compensate for static and dynamic alignment errors, and it has a maximum operating temperature of 392 degrees F. This roller bearing is intended for interchangeability and meets Deutsches Institut für Normung (DIN) standards for parts numbering, bearing dimensions, load ratings, tolerances, and clearances. It meets International Standards Organization (ISO) standards for hardening of bearing rollers and rings. This spherical barrel roller bearing is suitable for use in material handling equipment, electric generators, and machine tools.
Product features:
Two row spherical roller bearing suitable for applications that support high radial and oscillating axial loads
Two-piece pressed steel window-type cage has high wear resistance and spaces the rollers for even load distribution and prevents contact to reduce friction, vibration, and noise
Flangeless inner ring with cage guide
C3 radial clearance is larger than normal for applications where impact loads and vibration are severe, or thermal expansion is a factor
Straight bore fits conventional cylindrical shafts
MODEL | d(mm) | D(mm) | B(mm) |
23022CC/W33 | 110 | 170 | 45 |
23022CCK/W33 | 110 | 170 | 45 |
24022CC/W33 | 110 | 170 | 60 |
24022CCK/W33 | 110 | 170 | 60 |
23122CC/W33 | 110 | 180 | 56 |
23122CCK/W33 | 110 | 180 | 56 |
24122CC/W33 | 110 | 180 | 69 |
24122CC/K/W33 | 110 | 180 | 69 |
22222E | 110 | 200 | 53 |
22222EK | 110 | 200 | 53 |
23222CC/W33 | 110 | 200 | 69.8 |
23222CCK/W33 | 110 | 200 | 69.8 |
22322e | 110 | 240 | 80 |
22322ek | 110 | 240 | 80 |
23024CC/W33 | 120 | 180 | 46 |
23024CCK/W33 | 120 | 180 | 46 |
24024CC/W33 | 120 | 180 | 60 |
24024CCK/W33 | 120 | 180 | 60 |
23124CC/W33 | 120 | 200 | 62 |
23124CCK/W33 | 120 | 200 | 62 |
24124CC/W33 | 120 | 200 | 80 |
24124CCK/W33 | 120 | 200 | 80 |
22224E | 120 | 215 | 58 |
22224EK | 120 | 215 | 58 |
